601100
Size：05
Rated pressure：60 bar
Rated flow：15 L/min
• Fast response
• Compact size
• Wet DC solenoid
| General | |
| Weight | 0.235g |
| Installation orientation | optional,recommend installing vertically with the connector plug down. |
| MTTFd value | 150 year |
| Ambient temperature range | -30~80℃ |
| Hydraulic | |
| Max.operating pressure | PP = 60bar |
| Max. back pressure | PT = 30bar |
| Degree of contamination | Maximum permissible degree of fluid contamination: Class 9. NAS 1638 or 20/18/15 , ISO4406 |
| Fluid | Mineral oil (DIN 51524) |
| Fluid temperature range | 30~105℃ |
| Leakage | <100mL/min（power loss） |
| <100mL/min（power on） | |
| Filtration accuracy | 140μm（port P） |
| Electrical | |
| Operating pressure（Ampilfier） | 24V |
| Coil resistance（20℃） | 34 Ω |
| Connector form | DT04-2P Deutsch（Deutsch） |
| Degree of protection | IP6K6/IPX9K |
| Response Time | Commutation time<40ms |
| Response Time<40ms | |
