601100
• Ergonomic
• Precision proportional control, perfect adjustment characteristics
• Flexible and convenient operation
• Built-in buffering
• Diverse modular design
• Reliable dust and water resistance
• Ergonomic
• Precision proportional control, perfect adjustment characteristics
• Flexible and convenient operation
• Built-in buffering
• Diverse modular design
• Reliable dust and water resistance
| Type | PVH1 | PVH2 | PVH4 | |
| Inlet pressure | bar | Up to 60 | Up to 98 | |
| Back pressure at port T | bar | Up to 3 | ||
| Control fluid flow ( P to 1-2 ) | L/min | Up to 20 | ||
| Hysteresis | bar | Up to 1 | ||
| Pressure fluid | 1) suitable for NBR seals 2) suitable for FKM seals | Mineral oil (HL, HLP)1) to DIN 51524 Phosphate ester (HFD-R)2) | ||
| Pressure fluid temperature range | ℃ | -20 to +80 | ||
| Viscosity range | cSt | 10 to 380 | ||
| Degree of pressure fluid contamination | Maximum permissible degree of contamination of the pressure Maximum permissible degree of contamination of the pressure. Fluid is to NAS 1638 Class 9. We, therefore, recommend a filter with a minimum retention rate of ß10 ≥ 75 fluid is to NAS 1638 Class 9. We, therefore, recommend a filter with a minimum retention rate of ß10 ≥ 75. | |||
| Max. permissible operating torque at lever | Nm | 10 in operation | ||
| Weight | kg | 3.8 | 1.5 | 4.7 |
| Type | PVH3 | |
| Supply voltage | VDC | 7-36 |
| Baud rate | KBds | 250 |
| Operating angle | º | ±12 |
| Degree of protection | IP67 below mounting plate | |
| IP65 below mounting plate | ||
| Temperature | ℃ | -20 ~ 65 |
| Weight | kg | 1.2 |
